What are VCM household appliance plates and what production parameters do you offer?

Yes. We design and manufacture production lines & single machines according to customer requirements, including uncoiler, coiler, coating machines, printing units and looper systems. We can adjust strip width range, line speed, roller parameters and auxiliary devices. Our finished lines have been exported to Italy, Russia, Ukraine, Dubai, Algeria, Egypt, Iran, Tanzania, India, Bangladesh, Malaysia, Thailand, Vietnam, Cambodia and other countries.

Our colored aluminum printing line processes aluminum strip thickness 0.2-3 mm and width 800-1800 mm. The process speed ranges 20-120 m/min, max coating thickness 40 μm, printing ink layer ≤1 μm, annual output from 20,000 to 60,000 tons.

Our lines mainly adopt Siemens PLC system, with Profibus-DP / fiber-bus communication. Human-machine interface uses touch screen or WINCC. Alternative Yaskawa or mixed Siemens-Yaskawa control solutions are available. The system supports fault recording, parameter storage and full line tension & speed automatic control.

Yes. Our servo deviation correcting system applies to carbon steel, stainless steel, aluminum and copper strip lines for rolling, pickling, color coating, tension leveling and recoiling. It provides ±1 mm control precision, good anti-oil-pollution performance and stable long time running.

The catalytic incineration system treats organic waste gas from coating curing ovens. It burns VOCs at 220-350 ℃ and recycles combustion heat back to oven heating. It achieves 15%-35% energy saving, meets GB16297-1996 emission standard, and replaces multiple small burners with one high power combustion unit.

The sewing machine is used for head to tail connection of steel, copper, aluminum and galvanized strips. It can lock sew strip tail and next coil strip head without line stop. It has single row or double row sewing structure, short sewing time ≤10 s, and fits strip thickness up to 2.0 mm (aluminum up to 3.0 mm).
